Hammond Multi-Tap PRI, 119VA,50/60HZ 370EX
Category
Manufacturer
Item no.
- HA-370EX
Product weight
- 2,27 kg
Shipping weight
- 2,27 kg
Interesting items
Description
- Primary: Universal - 100, 110, 120, 200, 220,230, 240 VAC 50/60 Hz.
- NOTE: units are designed to operate with BOTH primary windings engaged.
- See primary wiring information under resources.
- V.A: 119
- A.C. High Voltage Secondary R.M.S: 550V C.T. @ 144ma.
- Bias Tap on High Voltage secondary with C.T Grounded (VAC): 50
- Filament #1 (VAC): 5V C.T. @ 3A
- Filament #2 (VAC): 6.3V C.T. @ 4A
- Primary: Universal - 100, 110, 120, 200, 220,230, 240 VAC 50/60 Hz.
- NOTE: units are designed to operate with BOTH primary windings engaged.
- See primary wiring information under resources.
- Bias Tap: 50 VAC tap from high voltage secondary C.T. (except part number 379WX - uses a separate 60VAC 0.2 Amp winding).
- Highpot tested: 2,000 VAC
- Faraday Copper Primary Shield: Our electrostatic shield reduces the capacitive coupling from the primary - greatly attenuating higher frequency current coupling to the secondaries (shield is internally grounded to the end bell).
- Windings: Concentric wound for low stray field and low noise.
- Models: This series is an upgrade from our entire 200 Series range of units PLUS 2 models designed specifically for 300B tubes (Part Number 300BX) and 2A3 tubes (Part Number 302AX).
- Finish: Black powder paint to match our 1650 series of output transformers Units can be run full wave bridge or full wave C.T.
- Conservative designs - CSA certified (209651).
- For a more economical, open frame, universal primary - check out our 260 Series.
- For that "high end" look & feel check out our potted versions - the 300P Series.
