Hammond Interstage Audio Transformer 126B
Interesting items
Description
- Designed for driver use ONLY in single ended tube output amplifiers. These units replace coupling capacitor circuits for improved sound.
- Audio: 4
- Impedance - Primary: 5K
- Impedance - Secondary: 5K
- Resistance - Primary: 178
- Resistance - Secondary: 178
- Inductance: 44 Henries
- Rated D.C. Bias Current: 30 ma.
- Designed for driver use ONLY in single ended tube output amplifiers. These units replace coupling capacitor circuits for improved sound.
- Closed style with minimum 8" long leads.
- All models use bifilar wound windings for exceptional coupling and bandwidth.
- Minimum frequency response 20 Hz. - 20 Khz (+/- 1db max. ref. 1 Khz.).
- The core is gapped to support the specified D.C. bias current.
- Maximum working voltage - 400 VDC
- Units are Hi-Pot tested at 1,000 VDC
- Core uses Hi grade silicon laminations (29M6).
- Units weight - 3 lbs. 2 oz.
