Hammond Audio Transformer 5K OHM 30 WATT 1645A

163,95 €

(137,77 € excl. vat)

Recommended retail price: 176,64 €

Scale price:

* Price per unit

including VAT., plus shipping

Order Now quantity: + (Increase quantity) - (Decrease quantity) Stk

Category

Manufacturer

Item no.

Product weight

Shipping weight

Interesting items

Mundorf MCap Classic 630V 0,47 uF ±3%

6,99 €
(5,87 € excl. vat)
including VAT., plus shipping
Hammond Choke 5H @ 300mA DC 193L

90,05 €
(75,67 € excl. vat)
including VAT., plus shipping

Features

NEW & improved version of our 1608-1650 Series multiple secondary output transformers (re-designed secondaries for easy hook-up of secondary loads).
Designed for push-pull tube output circuits.
Units are designed to provide ample "headroom" at bass frequencies (note the weight of each transformer).
All models have a secondary tapped for 4, 8 or 16 ohm outputs.
Enclosed (shielded), 4 slot, above chassis Type "X" mounting.
Manufactured with plastic coil forms for coil support and insulation.
Frequency response 30 Hz. to 30 Khz. at full rated power (+/- 1 db max. - ref. 1 Khz) minimum.
Insulated flexible leads 8" min.
All units (except the 1650G) include 40% screen taps for Ultra-Linear operation (if desired).
Typical applications - Push-Pull: triode, Ultra-Linear pentode, pentode and tetrode connected audio output. The 1650G does NOT have primary screen taps and will not support "Ultra-Linear" applications.
