Audio Toroidal Transformer "P2P" - Sec.: 500vct, 6.3vct, 5vct

Schematic | ![]() |
Wattage | 25W |
Primary (input) Impedance | 5K Ohms |
Screen/Grid Tap | 40% |
Secondary (output) Impedance | 8 Ohms |
Frequency Response | 20~20K Hz., <1dBu |
THD+Noise | <0.1% @ 1K Hz. |
Bobbin Material | Glass Filled Nylon 6/6 |
Flamability Rating | Class B 130°C |
Core Material | M6 29 ga. line grain oriented steel |
Termination | UL1015, 20 ga. lead wire |
Mounting | Powder coated steel end bells |
Weight | 4.5 lbs. |
Dimensional Drawing |
![]() |
Manual |
![]() |
